Kubernetes on Ubuntu 22.04: A Step-by-Step Guide

Let's dive into deploying Kubernetes on Ubuntu 22.04. This guide provides a comprehensive walkthrough to get your Kubernetes cluster up and running smoothly. Whether you're a seasoned DevOps engineer or just starting with container orchestration, this tutorial aims to make the process as straightforward as possible. We'll cover everything from setting up the necessary prerequisites to deploying your first application. Get ready to harness the power of Kubernetes!

Prerequisites

Before we begin, there are a few things you'll need to have in place. These prerequisites ensure a smooth installation process and prevent common issues down the line. Make sure you've got these covered before moving forward.

Hardware Requirements

First off, you'll need a machine running Ubuntu 22.04. I recommend at least 2 virtual machines or physical servers. Each node should have a minimum of 2 CPUs and 2 GB of RAM. More resources are always better, especially if you plan to run resource-intensive applications. For a small test environment, these specs should suffice, but for production, you'll likely want beefier machines. Adequate disk space is also crucial; start with at least 20 GB per node. Running out of disk space can lead to unexpected issues and downtime, so plan accordingly. Consider using SSDs for better performance, especially for etcd, Kubernetes' key-value store.

Operating System

Ensure you have Ubuntu 22.04 installed on each of your nodes. A fresh installation is always recommended to avoid conflicts with existing software. During the OS installation, create a user account with sudo privileges, as you'll need it for administrative tasks. After installing Ubuntu, make sure to update the system by running sudo apt update && sudo apt upgrade. This ensures you have the latest security patches and software updates. Keeping your system up-to-date is a fundamental security practice. Additionally, configure a static IP address for each node. DHCP can cause IP addresses to change, which can disrupt your Kubernetes cluster. Edit the /etc/netplan/ configuration file to set a static IP.

Container Runtime: Docker or Containerd

Kubernetes needs a container runtime to run containers. While Docker used to be the de facto standard, containerd is now widely adopted and officially supported. For this guide, we'll use containerd. To install containerd, first update your apt package index and install the necessary packages:

sudo apt update
sudo apt install -y containerd

Next, configure containerd by creating a configuration file:

sudo mkdir -p /etc/containerd
sudo containerd config default | sudo tee /etc/containerd/config.toml

Edit the /etc/containerd/config.toml file and change the SystemdCgroup option to true:

[plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options]
  SystemdCgroup = true

Finally, restart containerd to apply the changes:

sudo systemctl restart containerd
sudo systemctl enable containerd

Kubernetes Components: kubeadm, kubelet, kubectl

We'll use kubeadm to bootstrap the Kubernetes cluster, kubelet to run containers on each node, and kubectl to interact with the cluster. Install these components using apt:

sudo apt update
sudo apt install -y apt-transport-https ca-certificates curl
curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -
echo "deb https://apt.kubernetes.io/ kubernetes-xenial main" | sudo tee /etc/apt/sources.list.d/kubernetes.list
sudo apt update
sudo apt install -y kubelet kubeadm kubectl
sudo apt-mark hold kubelet kubeadm kubectl

The apt-mark hold command prevents these packages from being accidentally updated, which could lead to compatibility issues.

Setting Up the Control Plane

The control plane is the heart of your Kubernetes cluster. It manages the worker nodes and ensures that your applications are running as expected. Let's set it up.

Initializing the Kubernetes Cluster

On your designated master node, initialize the Kubernetes cluster using kubeadm. Specify the pod network CIDR and the control plane endpoint:

sudo kubeadm init --pod-network-cidr=10.244.0.0/16 --control-plane-endpoint="YOUR_MASTER_NODE_IP:6443"

Replace YOUR_MASTER_NODE_IP with the actual IP address of your master node. The --pod-network-cidr specifies the IP address range for pods in the cluster. The control-plane-endpoint is the address that worker nodes will use to connect to the control plane.

After the initialization is complete, kubeadm will output instructions on how to configure kubectl. Follow these instructions to set up your user context:

mkdir -p $HOME/.kube
sudo cp /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

Now you can use kubectl to interact with your cluster. Verify that the control plane is running:

kubectl get nodes

You should see your master node listed in the output, with a status of Ready.

Deploying a Pod Network

Kubernetes requires a pod network to enable communication between pods. We'll use Calico, a popular and flexible networking solution. Deploy Calico using kubectl:

kubectl apply -f https://docs.projectcalico.org/manifests/calico.yaml

This command applies the Calico manifest, which sets up the necessary components for pod networking. Wait a few minutes for the Calico pods to start running. You can check their status using kubectl:

kubectl get pods -n kube-system

Look for pods with names like calico-node and calico-kube-controllers. Once they are all in the Running state, your pod network is ready.

Adding Worker Nodes

With the control plane up and running, let's add worker nodes to the cluster. Worker nodes are where your applications will actually run.

Joining the Cluster

On each worker node, run the kubeadm join command that was outputted during the kubeadm init process on the master node. It should look something like this:

sudo kubeadm join YOUR_MASTER_NODE_IP:6443 --token YOUR_TOKEN --discovery-token-ca-cert-hash sha256:YOUR_HASH

Replace YOUR_MASTER_NODE_IP, YOUR_TOKEN, and YOUR_HASH with the values provided by kubeadm init. If you've lost the token, you can generate a new one on the master node:

sudo kubeadm token create --print-join-command

After running the kubeadm join command on each worker node, they will register with the control plane. Back on the master node, verify that the worker nodes have joined the cluster:

kubectl get nodes

You should now see all your worker nodes listed, along with the master node. Ensure that their status is Ready.

Deploying Your First Application

Now that your Kubernetes cluster is set up, let's deploy a simple application to test everything out. We'll deploy a basic Nginx web server.

Creating a Deployment

Create a deployment using kubectl: first create a file named nginx-deployment.yaml:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:latest
        ports:
        - containerPort: 80

This deployment creates three replicas of the Nginx container. Apply the deployment using kubectl:

kubectl apply -f nginx-deployment.yaml

Verify that the deployment was created successfully:

kubectl get deployments

You should see the nginx-deployment listed, with a status of Ready.

Creating a Service

To expose the Nginx deployment to the outside world, we'll create a service of type NodePort:

apiVersion: v1
kind: Service
metadata:
  name: nginx-service
spec:
  selector:
    app: nginx
  ports:
    - protocol: TCP
      port: 80
      targetPort: 80
      nodePort: 30000
  type: NodePort

Save this as nginx-service.yaml and apply it:

kubectl apply -f nginx-service.yaml

Get the service information:

kubectl get services

Find the nginx-service and note the node port (e.g., 30000). You can now access the Nginx server by navigating to http://YOUR_NODE_IP:30000 in your web browser, replacing YOUR_NODE_IP with the IP address of any of your worker nodes. You should see the default Nginx welcome page.

Conclusion

Congratulations! You've successfully deployed a Kubernetes cluster on Ubuntu 22.04 and deployed your first application. This is just the beginning. From here, you can explore more advanced Kubernetes features, such as deployments, services, namespaces, and more. Keep experimenting and learning, and you'll become a Kubernetes pro in no time! This guide provides a solid foundation for your Kubernetes journey. Feel free to refer back to it as you continue to build and deploy applications on your cluster. Remember to consult the official Kubernetes documentation for more detailed information and advanced topics. Good luck, and happy deploying!
